Stahlwille Sensotork - Testere digitale de moment 0.4-1100Nm

Pret recomandat:

0,00 RON TVA Inclus

In stoc producator

Cere termen de livrare

Nume:

Telefon:

Email:

Mesaj:

Scrieti codul
din imaginea
alaturata:

Inchide X

Cod: Sensotork 7707

Prod: Stahlwille

Pagina producatorului

Clasa: Profesionale

Detalii produs Inapoi

Download

Catalog prezentare

Manual de utilizare

7707 W - Workshop torque tester Sensotork®

Electronic torque tester for torque wrenches Sensotork® 7707 W

Compact workshop-based torque tester for easy adaptation by replacement of the transducers. High degree of accuracy thanks to flat transducer and conversion and digitalisation of readings within the transducer. High degree of safety through display showing actual torque read-off where clicking torque wrenches are used.Electronic workshop torque tester for torque wrenches, consisting of:

● transducer, patent
● holder
● display unit (registered design)
● tripod for display unit (with 1.5 m cable)
● spiral cable
● mains adaptor (110 V-230 V with interchangeable socket adaptors) or direct connection to 12 V in-car supply is possible
● square drive adaptor (No 7707-2W, No 7707-2-1W, No 7707-2-2W, No 7707-3W)
● kit for attaching the unit to a workbench or wall in a horizontal or vertical testing position for clockwise and anticlockwise use. Units of measurement: N m, ft.lb, in.lb. The easily interchangeable transducers are attached to the holder by means of a QuickRelease safety lock. Low lateral forces thanks to low-profile transducers, automatic detection of the transducer, flexible and user friendly because the unit can be used horizontally or vertically and the display unit can be placed in many positions, additional tripod with 1.5 m cable for mounting the display unit to facilitate visual monitoring when using longer torque wrenches, especially broad measuring range from approx. 2% to 100% of rated value. The software No 7759-4, including USB hub and jack cable , enables readings to be transferred to the PC for documenting and for generating calibration certificates in accordance with DIN EN 6789:2003 (no separate power supply needed, power comes from PC). While individual transducers are being recalibrated, the torque tester itself remains on-site for further use. Wide range of application (-20°C to +60°C). Complies with DIN 51309: 2005, Class 2 and DKD-R 3-8: 2003.

With certificate.
Supplied in sturdy plastic case.

QuickRelease
Rapid change and firm locking of the transducers thanks to the QuickRelease safety lock.

Interchangeable square drive adapters:
A set of interchangeable square drive adapters are conveniently stored in the mounting block for a range of different drive sizes.

Pentru oferta personalizata va rugam sa ne contactati.

Date tehnice

Code	Model	ISO	Imperial	Antrenare	Kg	Precizia*
96521080	7707-1W	0.4-20Nm	0.3-15ft.lb	1/4"	6.255	+/- 0.25%
96521072	7707-2W	2-100Nm	1.5-74ft.lb	1/4"+3/8"	7.025	+/- 0.25%
96521083	7707-2-1W	4-200Nm	3-148ft.lb	1/4"+3/8"+1/2"	7.511	+/- 0.25%
96521084	7707-2-2W	8-400Nm	6-295ft.lb	1/4"+3/8"+1/2"+3/4"	7.654	+/- 0.25%
96521082	7707-3W	25-1100Nm	18-812ft.lb	1/4"+3/8"+1/2"+3/4"	7.495	+/- 0.25%
* Precizia maxima obtinuta

Se livreaza cu certificat de calibrare emis de producator.

Aplicatii

Cu aplicatii in:
- Controlul calitatii - Automotive
- Controlul calitatii - Industria militara
- Controlul calitatii - Ansamblari - Industrie
- Controlul calitatii - Impachetare - Ansamblare - Industria bunurilor de consum
- Controlul calitatii - Domenii adiacente
- Laboratoare
- Cercetare

Informatii utile

Putem furniza diverse configuratii de testere, standuri analogice sau digitale pentru verificarea sau calibrarea surubelnitelor si cheilor dinamometrice. Recomandate pentru utilarea laboratoarelor de verificari metrologice, laboratoarelor de certificari sau pentru diverse aplicatii din mediul profesional.

Ofertele vor fi personalizate in functie de necesitatile de exploatare.
Asiguram recertificare si recalibrare periodica.

Pentru informatii suplimentare va rugam sa ne contactati.

Accesorii

Optional disponibil kit pentru transferul datelor, compus din software + harware.

Software-ul permite momorarea masuratorilor si emiterea de certificate de calibrare in concordanta cu DIN EN ISO 6789: 2003 care pot fi printate sau salvate in format PDF.
